Installation Guide
This Installation Guide provides instructions for installing AXIS Q1775 Network Camera on your
network. For other aspects of using the product, see the User Manual available at www.axis.com.

Installation Steps

1. Make sure the package contents, tools and other materials necessary for the installation
are in order. See page 9 .
2. Study the hardware overview. See page 9 .
3. Study the specifications. See page 14.
4. Install the hardware. See page 17.
5. Access the product. See page 18.

Package Contents

• AXIS Q1775 Network Camera
• 4-pin I/O connector block for connecting external devices to the I/O connector
• One 2-pin connector for power connection
• Two 2-pin connectors for RS-485/422 connection
• Metal stand supplied with mounting screws
• Allen key T20
• Printed materials
- Installation Guide (this document)
- Extra serial number label (2x)
- AVHS Authentication key

Hardware Overview

NO TICE TICE
NO NO TICE
Do not point the camera lens toward the sun or other high-intensity radiation sources
because this could cause damage to the camera.
AXIS Q1775 Network Camera
9
