The First Flight - Modster PAUL Betriebsanleitung

Manual
Controller Smartphone Holder:
Disconnect the two halves of the controller and
insert your smartphone (not included!).
Please take care that the holder /
Controller is not damaged!

4. The First Flight

Place the model on the ground at a distance of approx. 2-5m, first switch on the model (press the button on the top of the copier) and then
the transmitter. This will indicate by a beep that he is ready. Move the left joystick once completely upwards, then completely downwards. The
model is now connected to the copter and start-up. Please ensure that the binding process is completed within 5 seconds, otherwise it can
lead to considerable malfunctions. Repeat the binding process if necessary. Attention to the setting of the gyro system, the model must be
absolutely quiet and straight when switching on.
After switching on and binding the model, you can now start and end the model using the Start / Stop button. Press the button once, the
motors of the model begin to run. You can now use the left control lever to raise the model to the desired height (model as long as you push
the lever up), which then holds it. By pressing the button again, the model starts with the landing. Possible countersteering necessary when
drifting the model.
The model has an integrated height stabilization. That means that the model always maintains the height you steer independently.
Fly the model only within sight (about 30-40 meters), once you get out of range, the model is no longer controllable. Fly the wind with the
highest agility / speed stage („Speed" button of the remote control).
www.modster.at
MODSTER PAUL Pocket Drone
Additional Starting Option
In addition to the automatic start function, you have an additional start
option for the model.
Insert the battery of the model, switch on the remote control and move
the left stick once completely upwards and downwards again. The mo-
del is now connected with the remote control (complete the binding
process within 5 seconds, otherwise the model may malfunction!).
Now move both control sticks simultaneously diagonally downwards
(see picture). The engines of the model now start to run and you can
start the model manually (press the left lever up).
Reset function
To reset the model (reset to basic setting) proceed as follows:
• Turn on the model and connect it to the controller
• Press the Speed button until it beeps three times
• Now press both control levers downwards simultaneously and hold
them in this position for approx. 3 seconds.
• The copters' LEDs flash and then go into a continuous light. The cop-
ter is now resettet.
17
