14 Accessories, spare
parts and service
14.1 Accessories
FRWM-IP-GATE gateway for
FRWM radio networks
14.2 Spare parts
Currently none available
14.3 Service
In the event of a warranty claim, send the
device to your retailer.
If you have questions about the product
or require help with the installation, please
contact our product support department
by telephone at +49 2355 806 0.
38
Operating Manual: FR W M-AR Alarm Relay
15 Technical
Specifications
.
Power supply
Battery
Battery life
Material
Weight
Dimensions
Protection class
Floating con-
tact alarm input
Switching level
Alarm output
DC and/or AC
Peripheral cable with
wire cross-section
Radio frequency
Ambient Temperature
1 x 3,0V lithium
not replacabel
approx. 10 years
ABS
54 grammes
54 x 54 x 22 mm
IP 30
max. 24V
> 1,6 V
Relay with
changer, 3V to 30V
1-100mA
single wire
between
0.5 and 2.5 mm²
868,3 MHz
5 ... 35 °C
EN
EN
