Confi guration Set-up-Menu
e-Drive Function
Press e-Drive 1× short = activate
Press e-Drive for 3 seconds = confi rm
Note:
If e-Drive is pressed briefl y 1x without confi rmation, the values will not be saved.
Switch on mains
Standby mode
3 seconds
Blower interface setting
1× short
Display Description
Blower e-Drive
Blower interface specifi cation 0 – 10 V
Blower interface specifi cation 4 – 20 mA
Save
Operating mode
0 – 10 Volt
1× short
e-Drive Function
Turn to right
Turn to left
Set-up-Menu
&
Settings are saved.
Back to operating mode.
Press for 2 seconds and slowly
turn ¼ revolution to the right at
the same time
3 seconds
4 –20 mA
Press e-Drive for 5 seconds
Back to standby mode
19
