Leister MONO SYSTEM Bedienungsanleitung Seite 15

Technical data MONO 6 SYSTEM
Voltage
Power consumption
Frequency
Air volume max. (20 °C)
Max. air inlet temperature
Max. static pressure
Emission level
Weight
Size
Mark of conformity
Protection class II
Device function
Technical data for interface
Relay output
Signal inputs
with reverse polarity
protection and
zero off set
Setpoint setting
e-Drive or
interface
Technical data and specifi cations are subject to change without prior notice
V~
W
Hz
l/min.
°C
kPa
L (dB)
pA
kg
• Adjustable air volume
• Compact and effi cient
• "e-Drive" operating unit
Max. voltages
Max. currents
Max. contact resistance
Type of contact
Insulation IEC/EN 60065
Insulation IEC/EN 60747-5-2
Voltage input Uc in relation
to GND iso
Max. input voltage
Nominal input resistance
Current input Ic (2 - conductor
technology)
Max. input current
Nominal input resistance
e-Drive
External interface
120
• Brushless motor
• Tool protection
• System interface
AC 250 V, DC 30 V
AC 3 A, DC 3 A
100 m Ohm bei DC 6 V / 1 A
SPST - NO
AC 2000 V (50 - 60 Hz) 1 min
AC 1414 V Peak
DC 0 - 10 V
DC 12 V
7.9 kOhm
DC 4...20 mA
DC 22 mA
168 Ohm
1 – 100 %
1 – 100 %
230
250
50 / 60
250 – 600
65
3.5
65
1.0
