Display description

Symbols
Undervoltage
Voltage measurement
Indicator fi eld for visualizing units or information for the Service menu
Value fi eld for display of setpoint and actual values.
It is a four-digit segment display without decimal point
The bar graph in 5 steps symbolizes the fan speed.
At the same time, the display will appear in % (1 P - 100 P)
Blower fan speed 100 % max.

Operating

Switch on mains
Increase air volume in %
Turn e-Drive to right
18
Standby mode
Bar graph display fl ashes until the value is set.
Press e-Drive for 5 seconds
Back to standby mode
The values last set are saved.
Symbols
Contact your Leister Service Centres
Blower active
Blower fan speed 1 % min.
Press e-Drive
for 3 seconds
Reduce air volume in %
Turn e-Drive to left
