Overview
1
2
3
Using the Hex Charger
1. Connect the Hex Charger to a power outlet (100-240V, 50/60Hz) with the power cable.
2. Insert the Intelligent Flight Battery into the battery port, or connect the Remote Controller to the remote
controller port to begin charging. When the LED lights on the Intelligent Flight Battery or the Remote
Controller turn off, charging is complete and the device can be disconnected from the Hex Charger.
※ The TB47 series Intelligent Flight Battery and the TB48 series Intelligent Flight Battery take approximately 1
hour 30 minutes and 1 hour 50 minutes to fully charge respectively.
4
Hex Charger
1. Battery Port
2. Remote Controller Port
3. Power Port
4. Heat Vent
Power Outlet
©
