Unpacking the appliance

WARNING: Risk of injury!
The blades of the knife block are very sharp!
1. Remove the device from its packaging.
2. Remove all packaging materials like foils, fi lling materials, cable hold-
ers, and carton packaging.
3. Check the scope of deliveries for completeness.
4. Check the device for transport damage in order to avoid hazards.
NOTE:
There may still be dust or production remains on the device. We recom-
mend that you clean the device as described under "Cleaning".

Delivery contents

Please also refer to pages 3 and 4.
1 Base
1 Measuring cup (lid lock) (Fig. 1)
1 Lid with sealing washer (Fig. 2 + 3)

1 Simmering basket (Fig. 4)

1 Knife block with sealing washer (Fig. 5)
1 Wing nut with sealing washer (Fig. 5)

1 Blender (Fig. 6)

1 Stirrer (Fig. 7)
1 Blade guard (Fig. 8)
1 Spatula (Fig. 9)
1 Steam attachment consisting of steam container with sealing washer
(Fig. 3), insert and cover (Fig. 10)

Become familiar with your MKM 1104

Possible uses

This device combines 10 different kitchen appliances.
You may use it for
Shredding (chopping, grating, grinding, etc.)
Beating
Emulsifying
Pureeing
Mixing
Stirring
Kneading
Heating
Cooking
Steaming food.

Knife block (Fig. 5)

WARNING: Risk of injury!
The blades of the knife are very sharp! Hold the knife block by the upper
hexagon screw only (Fig. A).
The knife block is attached to the bottom of the blender by means of a
wing nut.
1. In order to uninstall the knife block, remove the blender from the
device.
2. Use your other hand to screw off the wing nut in anti-clockwise direc-
tion (Fig. B).
3. Carefully pull the knife block from the blender.
4. In order to reinstall the knife block again, follow the steps of uninstalling
in reverse order.
CAUTION:
Make sure the sealing washer of the knife block and the sealing washer
of the wing nut are correctly installed. If one of the sealing washers is
missing, the blender will be leaking. Leaking ingredients can damage the
device.
PC_MKM 1104_IM

Sealing washers of the lid and the steam container (Fig. 3)

The sealing washers prevent steam or ingredients from escaping from
between the lid and the blender during operation.
• Never operate the device without the sealing washers of the lid or the
steam attachment installed!
• Check the sealing washers regularly for damage.
• The sealing washers must be clean and properly installed with the
"FACE UP ↑ ESTA CARA A LA TAPA ↑" marking being visible.

Blender lid (Fig. 2)

NOTE:
• For safety reasons, the device can only start if the lid is properly in-
stalled and locked.
• Only close and open the lid when the blender is not interlocked with
the device. Never use force to open the lid!
• You may use the opening in the lid to refi ll ingredients during operation
without having to remove the lid.
1. In order to attach the lid, hold it in such a way that the
the lid is aligned with the handle.
2. First, place the gap of the lid onto the spout of the blender (Fig. E).
3. Lower the lid towards the handle and press down until it clicks into
place (Fig. F).
4. In order to open the lid, press the button (Fig. F/a) on the lid.
Blender (Fig. 6)
1. Before attaching the blender to the device, check the correct position-
ing of the knife block and the lid in order to ensure safe operation of
the device.
2. Observe the markings on the device and blender. Insert the blender
into the device, making sure the
marking.
3. Secure the blender by turning it anti-clockwise. The
be exactly aligned with the marking (Fig. G).
NOTE:
The level indicator inside the blender helps you not to exceed the maxi-
mum quantity.

Measuring cup (Fig. 1)

This accessory provides different functions:
• You may use the measuring cup to measure ingredients. Observe the
level indicator.
• When attaching the measuring cup to the lid with its opening facing up,
it locks the lid opening, preventing ingredients from spurting out of the
blender and at the same time preventing heat loss during cooking op-
eration.
• If you wish to slowly add liquids during operation (e.g. when emulsify-
ing), insert the measuring cup with its opening facing down, making it
unnecessary to remove the measuring cup. Pour the liquids onto the lid.
They will then slowly run into the blender. Please note: The measuring
cup provides for two different height settings.
Simmering basket (Fig. 4)
• Use the simmering basket to cook, for example, side dishes that are not
to be shredded.
• It can also be used as sieve, e.g. to separate liquids from pureed fruits.
Use the spatula to hold the simmering basket when pouring out liquids
(Fig. C).
• In order to remove the simmering basket from the blender, use the spat-
ula as well (Fig. D).
marking on
marking is aligned with the
marking must
