It is only to be used as instructed in this user
manual. The appliance is not intended for com-
mercial use.
Any other use shall be considered as not intended
use and can lead to material damage or even
personal injury.
The manufacturer shall not be liable for damages
caused by not intended use.

Supplied parts

1 base device with
motor
1 cap for the filler
opening
1 lid with filler opening
for mixing vessel

Unpacking the appliance

1. Remove the device from its packaging.
2. Remove all packaging materials like foils, filling
materials, cable holders, and carton packaging.
3. Check the scope of deliveries for completeness.

NOTE:
There may still be dust or production remains on
the device. We recommend that you clean the
device as described under "Cleaning".

Description of the Parts

1 Fill opening cap
2 Mixing jug lid with fill opening
3 Mixing jug
4 Blade block
5 Screw mount for the blade block
6 Drive wheel
7 Base unit with motor
8 Control panel
9 Function indicator lights
44
1 mixing vessel
1 blade block
1 screw mount for the
blade block

Assembly

Assemble the blade block (see Fig A and B)
1. Turn the mixing jug on its head.
2. Place the blade block onto the seal on the base
of the jug. The drive wheel points outwards.
3. Put the screw mount onto the thread on the
base of the mixing jug.
4. Left-handed thread! Turn the screw mount
anti-clockwise.
5. As soon as the screw mount is in contact with
the blade block, turn it again gently.
Attach the mixing jug (see Fig. C)
In order that you can attach the mixing jug more
easily, arrows have been put onto the housing. The
arrow on the mixing jug can be found directly below
the handle. Three arrows can be found on the base
unit with the motor. There are therefore three op-
tions for attaching the jug.
1. Position the mixing jug arrow around 3 centime-
tres to the right of the arrow on the base unit.
2. Turn the mixing jug clockwise until the arrows
are aligned.
3. The mixing jug is now connected to the base
unit.
4. Check it by trying to lift the mixing jug.
Put the lid on (see Fig. D and E)
1. Put on the black lid so that its tab closes the
spout on the mixing jug.
2. Put the fill opening cap into the black lid.
3. Give the cap a quarter turn clockwise to lock it.

Electric Connection

• Before inserting the power plug into the outlet,
check that the mains voltage to be used match-
es that of the device. You can find the required
information on the nameplate.
• Connect the device only to a correctly installed
safety socket.
