8 SCHEMATICS
8.7 ELECTRICAL CIRCUIT INSTRUMENTS & CONTROLS
1 Connector B
2 Connector A
3 Connector C
4 Connector D
5 Mow Switch
6 Indicator Switch
7 Lamp Switch
8 Beacon Switch
9 Hazard Illumination
10 Hazard Switch
11 Mow Switch Illumination
12 Fuel Gauge
13 Hour Meter
14 Engine Tenperature Gauge
15 Key Switch
16 Glow Plug Warning Lamp (Diesel only)
17 Alternator Warning Lamp
18 Blocked Filter Warning Lamp
19 Oil Pressure Warning Lamp
20 Engine Over Temperature Warning Lamp
21 Indicator Warning Lamp
22 Diode
23 Switch Illumination Lamp
24 Beacon Switch Illumination
