Fig. Item no.
1 –
7
8
9
10
11
1 12
1 13
1 14
1 15
1 16
1 17
– –

5 Preparation for Use

CAUTION
Incorrect alignment or assembly
Injuries due to fall resulting from damaged prosthesis components
► Observe the alignment and assembly instructions.
CAUTION
Use of powder (e.g. baby powder or talcum)
Skin irritation on the residual limb and loss of function of prosthetic components due to clogging
with particles or deprivation of lubricant
► Keep the product away from powders.
Inform the patient.
►

5.1 Preparing the Vacuum Pump

CAUTION
Contact with defective electrical components
Risk of injury due to electric shock
► Conduct a visual inspection before touching electrical components.
► Do not use damaged electrical components.
Inform the patient.
►

5.1.1 Inserting or Changing Batteries

The vacuum pump is operated with 2 rechargeable NiMH batteries, size AA. Operation with the
supplied batteries is recommended by the manufacturer. Alternatively the product can be oper­
ated with non-rechargeable batteries.
Required tools and materials:
>
709S51=T8 Offset Torx Screwdriver, 2 batteries (size AA)
Preparations required:
Disconnect the charger
1) Pull out the offset screwdriver on the side of the vacuum pump (see fig. 2).
2) Pull the vacuum pump off the adapter plate and loosen the outlet hose (see fig. 3, see fig. 4).
4R152* Harmony E2
Quantity Designation
– 1 Battery compartment screw
– 1 Locking screw
– 1 Hose connector
2 O-ring
4 Screw for adapter plate, 35 mm
4 Screw for adapter plate, 38 mm
1 Hose piece for outlet
1 USB charging plug
1 Power supply
1 Adapter plug (EU)
1 Adapter plug (US)
2 Battery, rechargeable, size AA
0 Socket connector
Reference number
–
501Z61=M12x1.5
–
627F13=7X1
501S128=M6X35
501S128=M6X38
4X220
4X269
757L1
757S7=EU
757S7=US
625B13
2R117
