SWEEP I & II
SWEEP INSTALLATION AND OWNERS MANUAL
INSTRUCTIONS D'INSTALLATION ET
MANUEL D'UTILISATION DE L'APPAREIL DE BALAYAGE
INSTALLATIONS - UND BETRIEBSANLEITUNG FÜR DEN
SWEEP SCHWIMMBADREINIGER
MANUAL DEL USUARIO Y
DE INSTALACIÓN DE LA BARREDORA
®
www.pentairpool.com
REV. A 2-9-04
P/N YYSWEEPMANUAL
Werbung
Verwandte Anleitungen für Pentair SWEEP I
Inhaltszusammenfassung für Pentair SWEEP I
- Seite 1 SWEEP I & II SWEEP INSTALLATION AND OWNERS MANUAL INSTRUCTIONS D'INSTALLATION ET MANUEL D'UTILISATION DE L'APPAREIL DE BALAYAGE INSTALLATIONS - UND BETRIEBSANLEITUNG FÜR DEN SWEEP SCHWIMMBADREINIGER MANUAL DEL USUARIO Y DE INSTALACIÓN DE LA BARREDORA ® www.pentairpool.com REV. A 2-9-04...
- Seite 2 The Pentair Sweep is designed for installation in pools that have been pre-plumbed for an automatic pool cleaner as well as those that have not. We recommend that the installation be done by an experienced Pool Dealer or Service Professional.
- Seite 3 The water supply from the booster pump into the pool go through the Wall Fitting. Wall Fitting should be located near the center of the pool as shown. 3A Pre-plumbed pool with Wall Fitting. Once the booster pump is installed, flush the water line from the booster pump to the pool.
- Seite 4 Feeder Hose Water under pressure from Wall Fitting to Sweep Head are carried through feeder hose (LD03C), one has 1 float only and the other has 4 floats. These floats are positioned as shown in drawing on following page. You need not adjust them. The extra float is optional for larger pools. There is one section of einforced white vinyl hose (LD03A) with Hose Weight (LD27) and fittings.
- Seite 5 Feeder Hose (cont.) D. Position feeder hose. Turn filter pump on, fill hose with water. When filled, walk free end of feeder hose to the furthest opposite diagonal corner. E. First, pull feeder hose towards you so that weight on the six foot section of white vinyl hose moves away from the wall with the feeder hose floating in the normal position.
- Seite 6 FIG. 5 Feeder Hose's Correct Length Feeder Hose S038 (LD03A) Mender And Weight S038 (LD27) S038 (LD30) S038 JVW1 LD03C EJ28 S038 ED05 S038 (ED15) LD03A LD27 (LD03C) ED05 (ED15) (ED05) LD41 Rotule A FIG. 5 Longueur De Boyau De Remplissage Boyau De Remplissage Jonction Et Flotteur S038...
- Seite 7 Hose Length Observe Pentair Sweep in deep end of pool, traveling forward, not backing up, noting the floor hose (longer of two hoses) as it passes leaf basket.
- Seite 8 (See Fig. 7). Connect Quick Disconnect (LD41) located on end of feeder hose to Outlet For Wall Pentair Sweep float arm. Immerse Sweep Head in water to displace any air. Turn filter pump on Hose (LG13) to fill with water. Turn Sweep pump on.
-
Seite 9: Maintenance
If you are in an area subject to periodic freezing conditions, but pool equipment is kept in operation, you should note the following: It is very important that filtering and Pentair Sweep systems be in operation during times when hard freezing occurs, normally between 1:00am and 6:00am. Running Pentair Sweep at this time will insure against damage and may prevent freezing of pool water. - Seite 10 Important Cleaning Instructions For JVW1 Wall Fitting To clean filter screen inside wall fitting: EJVW2 1. Disconnect feed line from wall fitting. 2. Unscrew wal fitting EF07 3. Remove filter screen inside and clean thoroughly. (Important to check and clean periodically). Instructions De Nettoyage Importantes Concernant L'Applique (JVW1).
- Seite 11 SWEEP PARTS LIST Part # Description Quantity ED15 Mender Nut, 5/8" Large (for feeder hose) LD03A Feeder Hose 6' Whire (reinforced) LD03C Feeder Hose 16' ED05 Swivel LD10 Hose Washer 3/4' LD15 Float Retainer LD27 Feeder Hose Weight LD30 Weight Retainer LD41 Quick Disconnect Swivel LF01...
- Seite 12 SWEEP PARTS LIST Descriptif Piece N Quantite ° Écrou de jonction de taille large (1,6 cm) pour boyau de remplissage ED15 Boyau de remplissage blanc de 1,9 m (renforcé) LD03A Boyau de remplissage de 4,9 cm LD03C Rotule ED05 Rondelle de boyau de 1,9 cm LD10 Dispositif de retenue de flotteur LD15...
- Seite 13 SWEEP PARTS LIST Bestell-Nr. Beschreibung Menge ED15 Gewindemuffe, 5/8 Zoll (15,9 mm) groß (für Zufuhrschlauch) LD03A Zufuhrschlauch, 1,8 m weiß (Panzerschlauch) LD03C Zufuhrschlauch, 4,9 m ED05 Drehgelenk LD10 Schlauchunterlegscheibe ¾ Zoll (19 mm) LD15 Schwimmerhaltering LD27 Gewicht für Zufuhrschlauch LD30 Befestigungsring für Gewicht LD41 Drehgelenk mit Schnelltrennkupplung...
- Seite 14 Arandela: 1,11 cm x 1,90 cm, plana de acero inoxidable LG06 Tuerca de la carcasa: 0,95 cm- acero inoxidable 16 LG09W Neumático de la carcasa (banda ancha Pentair) LG15A Tornillo de mariposa de 2,22 cm de acero inoxidable EG16A Muelle de compresión...
- Seite 15 EXPLODED VIEW VUE ÉCLATÉE EXPLOSIONSZEICHNUNG VISTA DETALLADA DE LF12 LF22 LD15 LF01 JVW1 EJVW1 LF21 EF01 LD41 EF07 ED15 ED15 ED05 LD30 LD27 ED15 LJ27 LG02 LD03A EB15 S038 ED15 LD03C LG63A LH10 LD03C LG09 EJ28 JVW1 LH05F S038 LH05W L01L ED05 LG06...
- Seite 16 ® Pentair Pool Products, Inc. 800-831-7133 Pentair Water Belgium +32 14 25 99 11 www.pentairpool.com 2/04 P/N YYSWEEPMANUAL Printed in USA Pentair Pool Products, Inc.
