User Instructions

Preparations for Installation

Before installing the Multi-room kit check that the following items are included in
the box.
• Warranty Card (with instruction manual)
•
Remote Control Handset
•
2 AAA Batteries
•
Multi-room RF receiver
•
Signal routing PCB card (for fitting by an authorised Cyrus agent).
•
4- pin Mini-DIN cable
After removing these items, please retain the packaging.
Install the Multi-room kit in a location away from sources of high temperature,
dust or humidity.
3
Cyrus Quattro Multi-room kit
Multi-room kit components
The kit components function as follows-
Remote Control handset
This sends remote control commands to the main Quattro system through a
high frequency wireless link.
Multi-room RF receiver
The Multi-room RF receiver module receives the wireless signals from the
handset and feeds the commands to the main Quattro unit through a miniature
DIN cable (supplied).
Switcher PCB
The Switcher PCB is fitted internally into the main Quattro unit, adding three
extra volume control stages to feed three additional Zone power amplifiers.
Installing the Switcher PCB into the Cyrus Quattro
The Switcher PCB should have already been installed by a Cyrus dealer or
agent inside the main Quattro unit when the Multi-room kit was purchased.
The installation can be checked by checking the introduction display when
power is first applied to the main Quattro unit. If the Switcher PCB is correctly
installed the legend 'Multi-room' will appear in the Installed: list on the display.
