User Instructions
Operating the Multi-room system
Key to the remote control and front panel drawings (Refer to Fig.2):
8. Volume keys 14.
9. Next/Previous keys 15.
10. Mute key 16.
11. Zone 3 select key 17.
12. Zone 2 select key 18.
13. Zone 1 select key
Fitting the Batteries to the Remote Control
The batteries (supplied) must be fitted to the remote control before use. To fit
the batteries, remove the battery compartment cover and insert two AAA
batteries (supplied) into the battery compartment. Observe the polarity markings
on the batteries and battery compartment. Replace the cover.
5
Remote Control Indications
The system has several features to indicate that a command is being sent.
1. When a remote control button is pressed, the Indicator light 1^ flashes to
Tuner select key
show that a command has been sent.
CD select key
2. For some commands you will also hear a 'beep' from the speakers so that
Receive (RX) light
you know you are in the correct Zone.
Power light
3. The RX light 1& on the Multi-room RF receiver box will light.
Power light
4. The display of the main Quattro unit will change briefly to show the Zone
number.

Standby operation

To switch the main Quattro system on with the remote control, press one of the
Zone keys 1! – 1#.
To switch the system to Standby, hold the mute key for a few seconds.
You will hear a beep through the speakers as the system mutes, followed by a
double beep to confirm that Standby is set.
Selecting or Changing a Zone
Press once on the required Zone number key 1! – 1#.
You will hear a beep through the speakers in the selected zone when one of
these commands are received.
Cyrus Quattro Multi-room kit
GB
GB
