Remotely controlled functions
Pre-attenuation ..........................0/–6/–12/–18 dB
High-pass fi lter ..........................Off /40/80/160 Hz
Digital gain .........................................0...10...63 dB
in steps of 1 dB, clickless
Test signals ..........................Off , 1 kHz (–48 dBFS),
Pink noise (–35 dBFS),
White noise (–43 dBFS)
Compressor/Limiter ..................................... On/Off
Lower cut-off frequency
of the working range ..........Flat/1 kHz/2 kHz/4 kHz
Max. gain reduction:
Flat mode ...................................................... > 63 dB
1 kHz/2 kHz/4 kHz ........................................ > 20 dB
Compression ratio .........................1,2:1/1,5:1/2:1/
3:1/4:1/6:1/8:1/>100:1
Threshold ........................–63 dBFS..–10...0 dBFS,
in steps of 1 dB
Attack time ............. 0/0,1/0,3/1/3/10/30/100 ms
Release time ..................0,05/0,1/0,2/0,5/1/2/5 s
(for a level change of approx. 10 dB )
Peak limiter ................................................... On/Off
Attack time .................................–160 µs (negative)
Release time .................. Approx. 50 ms to 150 ms
(signal-dependent)
Threshold ......................................Off : 0 dBFS fi xed
On: –15 dBFS to 0 dBFS,
in steps of 1 dB
Mute ............................................................... On/Off
Phase (polarity) ......................................... 0°, 180°
Signal light ............................................ LED (blue),
brightness adjustable
Sampling rates .................................44,1/48/88,2/
96/176,4/192 kHz
(Factory setting depending on version supplied.)
Synchronization
Asynchronous operation (free-running),
basic frequency accuracy ........................ ± 25 ppm
Synchronous operation,
pull-in range ................................... Min. ± 100 ppm
Power supply
(phantom power complying with AES 42)
Supply voltage range .......................+7 V to +10,5 V
Current consumption .........................Max. 150 mA
Connector ..................................................... XLR 3 M
Dimensions ......................................Ø 22 x 108 mm
Weight .................................................80/82/88 g
Factory settings are indicated in bold. If the DMI is used, they
can be changed at any time via the Remote Control Software.
US
GB
10 10
7. Accessories (see photos in appendix)
*
Connection Kits & Battery Pack
Connection Kit AES/EBU................Cat. No. 08584
Connection Kit S/PDIF ...................Cat. No. 08585
Battery Pack BP-04-N ....................Cat. No. 08586
Capsules
KK 183 .....................ni ....................Cat. No. 08566
KK 183 nx ................nx ...................Cat. No. 08567
KK 184 .....................ni ....................Cat. No. 08568
KK 184 nx ................nx ...................Cat. No. 08569
KK 185 .....................ni ....................Cat. No. 08570
KK 185 nx ................nx ...................Cat. No. 08571
Elastic Suspensions
DA-KM ......................blk ..................Cat. No. 08420
EA 2124 A mt ...........blk ..................Cat. No. 08433
Table Stands, Goosenecks
MF 2 .........................blk ..................Cat. No. 07266
MF 3 .........................blk .................. Cat. No. 07321
SMK 8 i .....................blk .................. Cat. No. 06181
Auditorium Hanger
MNV 21 mt ...............blk ..................Cat. No. 06802
Stand Mounts, Misc. Mechanical Adapters
DS 21 mt...................blk ..................Cat. No. 06798
DS 120 .....................blk ..................Cat. No. 07343
SG 21/17 mt ............blk ..................Cat. No. 06149
Windscreens / Windjammer
WKD-KM ..................gr ....................Cat. No. 08424
WJ-KM ......................gr ....................Cat. No. 08426
Foam Windscreens
WNS 100 .................black ..............Cat. No. 07323
WS 100 ....................blk .................. Cat. No. 06751
Popscreen
PS 15 ......................blk ..................Cat. No. 08472
Connecting Cables
IC 3 mt ....................blk ..................Cat. No. 06543
IC 31 mt....................blk ..................Cat. No. 06570
Meaning of color codes:
ni = nickel, nx = nextel, sw = black, gr = grey
6)
* Detailed descriptions and additional articles can be found
in our accessories catalog or at: www.neumann.com
8. Equipment supplied
Microphone Microphone stereo set
KM 1xx D (nx) 2 KM 1xx D (nx)
microphone microphones
SG 21 stand mount 2 SG 21 stand mounts
WNS 100 windscreen 2 WNS 100 windscreens
Operating manual Operating manual
Wooden case Wooden case
9.

Troubleshooting

▶
Problem Possible causes
Microphone not Supply voltage not activated
operating /
No signal
transmission
The microphone is not connected
to an AES 42 input
The microphone is not connected
to the right channel
The channel is muted
Distorted Excessive sound pressure of the
sound / signal to be recorded
bad signal
Overload due to low-frequency
quality
interference (e.g. impact sound
or wind)
No Operation is set to asynchronous
synchronization mode
The sample rates of the micro-
phone and the subsequent equip-
ment do not correspond with one
another
An external word clock is
detected but does not conform to
specifi cations
Output stage Starter set
KM D (nx) microphone KM 184 D nx microphone
output stage
SG 21 stand mount SG 21 stand mount
WNS 100 windscreen WNS 100 windscreen
Operating manual Connection Kit
Wooden case Operating manual
Wooden case
▶
Solution
Check the power supply device and if necessary
the associated software settings (RCS -> System ->
MicPWR).
Use an AES 42 input.
Check the signal path.
If necessary, activate the appropriate input on the
corresponding channel of the mixing console.
Deactivate the mute in the AES 42 remote control.
Take a more distant microphone position or activate
the pre-attenuation in the AES 42 remote control.
Use an appropriate windscreen (accessory). Activate
the pre-attenuation in the AES 42 remote control.
Use an appropriate popscreen (accessory). Activate
the pre-attenuation in the AES 42 remote control.
Activate the synchronization of the AES 42 input
(mode 2, RCS).
Synchronize the digital input with the source.
Use a sample rate converter.
Check the external word clock for precision and signal
quality (e.g. check for jitter or very long cables).
Alternative solution: Use the internal DMI word clock
as the master word clock for the entire signal chain.
