9.2 Settings
m NOTE
To make adjustments to the product, the robotic lawn-
mower (1) must be switched on. Switch on the robotic
lawnmower (1) by pressing and holding the
("POWER ON/OFF" button) until "PIN" appears on
the display.
9.2.1 Changing the PIN code (Fig. 21)
• Press and hold the "START" and "HOME" buttons
simultaneously for at least 3 seconds.
• The symbol and "PInI" flash.
• Now enter the old PIN code as follows (factory set-
ting "0000").
• The first digit illuminates ("0---").
• Use the "START" and "HOME" buttons to select the
desired digit.
• Confirm the digit with the "OK" button.
• The next digit illuminates (e.g. "10--).
• Proceed as described in paragraph 2-4 above.
• After you have entered the "old" PIN code and con-
firmed the fourth digit with the "OK" button, "PIn2"
appears, now you can enter the new PIN code.
• The first digit flashes ("0---").
• Use the "START" and "HOME" buttons to select the
desired digit.
• Confirm the digit with the "OK" button.
• The next digit flashes (e.g. "10--).
• Proceed as described in paragraph 2-4 above.
• After confirming the fourth digit with the "OK" but-
ton, the new PIN code is stored. The word "IdLE"
appears on the display.
9.2.2 Setting/changing the date/time(Fig. 22)
m NOTE
Date and time are necessary settings so that the ro-
botic lawnmower (1) can mow in accordance with the
set mowing schedule.
• The date/time setting is done in the order year -
date - time.
• Press and hold the "START" button for at least 5
seconds.
• The -symbol and a number (e.g. 2020) flashes
on the display.
• Use the "START", "HOME" and "OK" buttons to set
the year, similarly to the PIN setting.
• Then the next number illuminates (month.day e.g.
08.25 for 25 August).
• Use the "START", "HOME" and "OK" buttons to set
the correct month and day.
• The time is displayed last (e.g. 13:25).
• Set the current time as described above.
• After confirming the fourth digit with the "OK" but-
ton, the date and time are stored. The word "IdLE"
appears on the display.
36 | GB
9.2.3
The factory-set start time of 09:00 can be changed
at any time.
• Press and hold the "START" and "OK" buttons si-
button multaneously for at least 3 seconds.
• The display shows the set start time, e.g. 13:25,
with the first digit flashing.
• Use the "START" and "HOME" buttons to select
the desired digit and confirm with the "OK" button.
• Proceed as described in paragraph 2-4 above.
• After confirming the fourth digit with the "OK" but-
ton, the new start time is stored. The word "IdLE"
appears on the display.
9.2.4
The factory-set mowing time per day of 6 hours can
be changed at any time.
• Press and hold the "OK" button for at least 3 seconds.
• The display shows the set mowing time, e.g. 06 H,
with the first digit flashing.
• Use the "START" and "HOME" buttons to select
the desired digit and confirm with the "OK" button.
• After confirming the second digit with the "OK" but-
ton, the new mowing time or the new day is stored.
The word "IdLE" appears on the display.
9.3 Edge mowing
The default setting is for the robotic lawnmower (1) to
mow the edges every Tuesday and Friday.
This means that the robotic lawnmower (1) travels
once along the boundary wire (11) the first time it
mows for the day.
m ATTENTION
In this mode, the blade disc (6) is active.
The times for edge mowing can only be set via the app.

9.4 App control

The RRMA500 APP robotic lawnmower can be op-
erated via app. The app is available in the respective
app stores for Android and iOS.
m ATTENTION
The use of the app falls under the term "using" as
defined in this operating manual. Therefore, also
observe the safety regulations that apply to this.
www.scheppach.com
Changing the start time (Fig. 23)
Changing the mowing time/day (Fig. 24)
