• Use the "START" and "HOME" buttons to select the
desired digit and confirm with the "OK" button.
• Proceed as described in paragraph 2-4 above.
• After confirming the fourth digit with the "OK" but-
ton, the new start time is stored. The word "IdLE"
appears on the display.
9.2.4 Changing the mowing time/day (Fig. 24)
The factory-set mowing time per day of 6 hours can
be changed at any time.
• Press and hold the "OK" button for at least 3 sec-
onds.
• The display shows the set mowing time, e.g. 06 H,
with the first digit flashing.
• Use the "START" and "HOME" buttons to select the
desired digit and confirm with the "OK" button.
• After confirming the second digit with the "OK" but-
ton, the new mowing time or the new day is stored.
The word "IdLE" appears on the display.
9.3 Mowing edges
The default setting is for the robotic lawnmower (1) to
mow the edges every Tuesday and Friday.
This means that the robotic lawnmower (1) travels
once along the boundary wire (11) the first time it
mows for the day.
m ATTENTION
In this mode, the blade disc (6) is active.
The times for edge mowing can only be set via the
app.

9.4 App control

The RoboCut L500 APP robotic lawnmower can be
operated via app. The app is available in the respec-
tive app stores for Android and iOS.
m ATTENTION
The use of the app falls under the term "using"
as defined in this operating manual. Therefore,
also observe the safety regulations that apply to
this.
The robotic lawnmower has two different working
methods. In the original condition as delivered, the
robot works offline. The default range of robot mow-
ing functions are available.
32 | GB
If you wish to use additional services (mowing times,
software update, sensor settings, etc.), an additional
app is available but this is not provided by the Schep-
pach Group. You must enter your contact informa-
tion before you can connect this app to our robot-
ic lawnmower. An e-mail address is sufficient here.
The APP manufacturer has provided a data privacy
statement and a user agreement for this, which regu-
lates use of the app or your personal data.
We would like to advise you that the Scheppach
Group will not save any personal data when you
use the app and will also not process any further
information. This is only done by the app manu-
facturer.
9.4.1 Registration
In order to use the app, registration via email is nec-
essary. Alternatively, you can also register and log in
via Facebook, with your Apple ID or with google.
Have the serial number of your robotic lawnmower
ready for registration. You will find this on the type
plate of the unit.
9.4.2 Communication / data transmission
The app communicates with the robotic lawnmower
either via Bluetooth or WiFi.
m NOTE
Depending on your contract with your mobile phone
provider or internet provider, the data transfer from
the app to the internet may incur costs that you will
have to bear yourself.
9.4.3 Functions of the app
• Viewing and editing the mowing plan
• Adjusting the mowing zones
• Starting mowing
• Send the device to the charging station
• Settings
• Updates / read out (log data)
2
S/N:
Art-Nr.: 5913004917 55
. n . 36 Wh . RMA312S20V
0V : 2800 min -1
0
Ø 18 cm . 8,0 kg . IPX5
manufactured: 01/2023 S.Nr.: 0169-01001
S/N:
Scheppach GmbH - Günzburger Straße 69 - 89335 Ichenhausen - Germany SN:2201168000XX00000001
