App Functions; Cleaning - Scheppach Rrma500App Originalbetriebsanleitung

The robotic lawnmower has two different working
methods. In the original condition as delivered, the
robot works offline. The default range of robot mow-
ing functions are available.
If you wish to use additional services (mowing times,
software update, sensor settings, etc.), an additional
app is available but this is not provided by the Schep-
pach Group. You must enter your contact informa-
tion before you can connect this app to our robot-
ic lawnmower. An e-mail address is sufficient here.
The APP manufacturer has provided a data privacy
statement and a user agreement for this, which regu-
lates use of the app or your personal data.
We would like to advise you that the Scheppach
Group will not save any personal data when you
use the app and will also not process any further
information. This is only done by the app manu-
facturer.
9.4.1 Registration
In order to use the app, registration via email is nec-
essary. Alternatively, you can also register and log in
via Facebook, with your Apple ID or with Google.
Have the serial number of your robotic lawnmower
ready for registration. You will find this on the type
plate of the unit.
9.4.2 Communication / data transfer
The app communicates with the robotic lawnmower
either via Bluetooth or WiFi.
m NOTE
Depending on your contract with your mobile phone
provider or internet provider, the data transfer from
the app to the internet may incur costs that you will
have to bear yourself.
9.4.3

App functions

• Viewing and editing the mowing plan
• Adjusting the mowing zones
• Starting mowing
• Send the device to the charging station
• Settings
• Updates / read out (log data)
9.4.3.1 Viewing and editing the mowing plan
With this function you can set when the robotic lawn-
mower should start mowing and how long it should
Art-Nr.: 3913001xxx
20V . n : 2800 min . 36 Wh
-1
0
Ø 18 cm . 8 kg . IPX5
manufactured: 12/2020 S.Nr.: 0169-01001
Woodster GmbH - Günzburger Straße 69 - 89335 Ichenhausen - Germany
www.scheppach.com
mow for each individual day.
There is one start time per day (later max. two start
times) available.
In this function you can also set the days on which
the lawn edges are to be mown.
m ATTENTION
Changing the mowing schedule, starting a mow-
ing operation, switching the automatic on and
off, sending the robotic lawnmower home and
changing the date and time may result in activ-
ities that are not expected by other people. Af-
fected persons must therefore always be in-
formed in advance about possible activities of
the robotic lawnmower.
9.4.3.2 Adjusting the mowing zones
In this function you can manually set up four differ-
ent mowing zones in %. By default, the function is
set to "AutoMultizone". Here, the mower starts after
each charging process at an arbitrary place along
the boundary wire.
This means:
After the first charging process, the robotic lawn-
mower moves along the boundary wire in accord-
ance with the set % number for zone 1 and starts
mowing.
After the second charging process, it does the same
in accordance with the set % number for zone 2, etc.
Do not use chain saw for purposes not intended.
You have installed 200 m of boundary wire and set a
value of 25% for zone 1.
After charging, the robotic lawnmower drives 50 m
along the boundary wire and starts mowing from there.
m NOTE
This function allows you to start the robotic lawn-
mower in difficult-to-reach passages, for example, to
ensure a perfect mowing pattern.

10. Cleaning

m ATTENTION
Switch off the product before cleaning with the
m ATTENTION
Put on protective gloves before cleaning the rotating
blade carrier.
We recommend that you clean the product directly
after every use.
Clean the product at regular intervals using a damp
cloth and a little soft soap. Do not use any cleaning
agents or solvents; they could corrode the plastic
parts on the product. Make sure that no water can
penetrate into the product interior.
button.
GB | 37
