• Use the product in the way that is recommended in
this operating manual. This is how to ensure that your
product provides optimum performance.
• Furthermore, despite all precautions having been met,
some non-obvious residual risks may still remain.
WARNING
This power tool generates an electromagnetic field
during operation. This field can impair active or passive
medical implants under certain circumstances. In order
to prevent the risk of serious or deadly injuries, we rec-
ommend that persons with medical implants consult
with their physician and the manufacturer of the medical
implant prior to operating the power tool.
WARNING
In case of extended working periods, the operating per-
sonnel may suffer circulatory disturbances in their
hands (vibration white finger) due to vibrations.
Raynaud's syndrome is a vascular disease that causes
the small blood vessels on the fingers and toes to
cramp in spasms. The affected areas are no longer
supplied with sufficient blood and therefore appear ex-
tremely pale. The frequent use of vibrating products can
cause nerve damage in people whose circulation is im-
paired (e.g. smokers, diabetics).
If you notice unusual adverse effects, stop working im-
mediately and seek medical advice.
ATTENTION
The product is part of the 20V IXES series and may on-
ly be operated with batteries of this series. Batteries
may only be charged with battery chargers of this se-
ries. Observe the manufacturer's instructions.
WARNING
Follow the safety and charging instructions
and correct usage given in the instruction
manual of your 20V IXES Series battery and
charger. A detailed description of the charging
process and further information are provided
in this separate manual.
8

Operation

The cordless impact screwdriver has a clockwise/anti-
clockwise rotation, a ½ inch square bit holder and an LED
work light.
Please refer to the following descriptions for the function
of the operating parts.
WARNING
Danger of injury!
Remove the battery from the power tool before carrying
out any work on the power tool (e.g. maintenance, tool
change, etc.) and when transporting and storing it.
There is a risk of injury if the on/off switch is operated
unintentionally.
ATTENTION
Make sure that the ambient temperature does not ex-
ceed 50°C and does not fall below -20°C during work.
16 | GB
ATTENTION
The product is part of the 20V IXES series and may on-
ly be operated with batteries of this series. Batteries
may only be charged with battery chargers of this se-
ries. Observe the manufacturer's instructions.
8.1 Add/remove insert tool
CAUTION
Keep your hands away from the tool attachment when
the product is in operation.
1. Insert the required socket (11) into the ½ inch square
socket (1).
2. To remove, pull the socket (11) from the ½ inch
square socket (1).
Note:
ATTENTION
Only use sockets, that are suitable for impact screw-
drivers. Always choose the right size sockets for nuts
and bolts.
8.2 Mounting the belt clip (9)
1. During work breaks, the product can be hooked onto
the belt with the integrated belt clip (9).
2. Screw the belt clip (9) with the screw (10) to the right
or left screw-on point on the product, as required. Use
a Phillips screwdriver for this (not included in the
scope of delivery).
Note:
Make sure that the product is switched off and secured
against being switched on.
8.3 Inserting/removing the battery (3)
into/from the battery mount (4)
(Fig. 2)
Inserting the battery
1. Put the rotational direction switch (2) in the middle po-
sition (lock).
2. Push the battery (3) into the battery mount (4). The
battery (3) clicks into place audibly.
Removing the battery
1. Press the unlock button (5) of the battery (3) and re-
move it from the battery mount (4).
8.4 Test run
Note:
Before the first work and after each tool attachment
change, carry out a test run without load. Switch off the
product immediately if the tool attachment runs out of
round, there is considerable vibration or abnormal noises
are heard.
1. Before operation, check that the insert tool is correctly
fitted, i.e. centred on the ½ inch square holder (1).
