Scope of delivery/accessories

Unpack the device and check that
everything is present.
Dispose of the packaging material properly.
• Cordless Hedge Trimmer
• Blade guard
• Translation of the original instructions
The rechargeable battery and charger are
not included in delivery.

Overview

The illustrations for the device
can be found on the front fold-
out page.
1 Stop protection
2 Safety cutter bar
3 Hand protection
4 Safety switch
5 Front handle
6 On/Off switch
7 Handle
8 Battery holder
9 Battery
10 Battery release
11 Charge level indicator
12 Button (Charge level indicator)
13 Charger
14 Blade guard
15 Suspension system (Blade guard)
Fig. C
16 Keyhole
Fig. D
17 Screw

Description of functions

The device is powered by an electric motor.
The cutting unit of the device is a double-
sided safety cutter bar. During the cutting
process, the cutting teeth move back and
forth linearly. The stop guard at the tip of the
safety cutter bar prevents unpleasant kick-
backs when hitting walls, fences, etc. To
protect the user, the device can only be op-
erated with the safety switch pressed. The
hand guard also protects against branches
and twigs. Please refer to the descriptions
below for information on how the operating
elements work.

Technical data

Cordless Hedge Trimmer ... PHSA 20-Li C3
Rated voltage U ..................................20 V ⎓
Weight with battery (20 V, 2 Ah) ........≈2.9 kg
No-load rotation speed n
Stroke rate n ...........................2600 min
max
Cutting length ................................. ≈505 mm
Blade length (including stop protection)
.........................................................≈585 mm
Blade tooth spacing ......................... ≈20 mm
Branch diameter ............................... ≤15 mm
Sound pressure level (L
......................................... 79.4 dB; K
Sound power level (L
– Guaranteed ........................................90 dB
– Measured ................87.4 dB; K
Vibration (a ) ..................................................
h
– Handle ....................3.507 m/s²; K=1.5 m/s²
– Front handle ...........2.819 m/s²; K=1.5 m/s²
Battery .................................................. Li-Ion
Temperature ........................................≤50 °C
– Charging .........................................4–40 °C
– Operation ................................... −20–50 °C
– Storage ...........................................0–45 °C
PARKSIDE Performance Smart battery
Smart PAPS 204 A1/Smart PAPS 208 A1/
Smart PAPS 2012 A1
– frequency band ..............2400–2483.5 MHz
– transmitted power ........................ ≤20 dBm
Levels of noise and vibration were determ-
ined according to the standards and regula-
tions in the declaration of conformity.
The specified total vibration value and the
stated noise emission value have been
measured according to a standardised test
method and can be used to compare one
power tool with another. The specified total
vibration value and the stated specified noise
emission value can also be used for a provi-
sional assessment of the load.
WARNING! The vibration and noise emis-
sions may deviate from the specified values
during actual use of the power tool, depend-
ing on how the power tool is being used.
Try to keep the exposure to vibrations as
