Technical specifications

Device short description:
Supply voltage:
Current consumption:
Battery life:
Degree of protection:
Ambient temperature:
Dimensions (W x H x D):
Dimensions stainless steel mast (h x ø)
Weight:
Radio frequency band:
Maximum radiated power:
Receiver category:
Typ. open area RF range:
Duty cycle:
Method of operation:
Degree of pollution:
Measurement interval:
Technical specifications
HmIP-SWO-B
3x 1.5 V LR6/mignon/AA
50 mA max.
2 years (typ.)
IP22
-20 to +55 °C
15 x 42 x 15 cm
(not incl. stainless steel mast)
1.58 m x 25 mm
463 g (including batteries)
868.0-868.6 MHz
869.4-869.65 MHz
10 dBm
SRD category 2
400 m
< 1% per h/< 10% per h
Type 1
2
between 120 and 184 s
