clockwise and pulling it downwards.
Remove the empty batteries from the battery compartment (E).
•
• Insert three new 1.5 V LR6/mignon/AA batteries into the battery
compartment, making sure that you insert them the right way
round (see figure 7).
• Close the housing again by pushing and turning the cylinder
clockwise until it latches into place.
Once the batteries have been inserted, the weather sensor will perform a
self-test (approx. 2 seconds). Afterwards, initialisation is carried out. The
LED test display will indicate that initialisation is complete as the system
LED (C) lights up orange and green.
Caution! There is a risk of explosion if the battery is not replaced
correctly. Replace only with the same or equivalent type. Never
recharge standard batteries. Do not throw the batteries into a fire.
Do not expose batteries to excessive heat. Do not short-circuit
batteries. Doing so will present a risk of explosion.
Used batteries should not be disposed of with regular domestic
waste! Instead, take them to your local battery disposal point.
8

Troubleshooting

8.1

Weak batteries

Provided that the voltage value permits it, the weather sensor will remain
ready for operation also if the battery voltage is low. Depending on the
particular load, it may be possible to send transmissions again repeatedly,
Troubleshooting
29
