Mounting

Before starting to set-up the device, you have to connect the single com-
ponents of the weather sensor supplied. To do this, please proceed as
follows:
Step 1:
• Remove the not yet completely assembled weather sensor and
the anemometer (A) from the packaging.
• Put the anemometer to tube 2 (F) above the main sensor (B).
• Please make sure that the notch of the rotary axis matches with
the screw hole (see fig. 4).
• Fasten the anemometer with the screw (see fig. 5).
Step 2:
You can install the weather sensor using the stainless steel mast (F) or
using the hose clamp (I) and the tube connector (H) for mounting the
device to other tubes or mounting brackets.
Alternative A: Mounting with stainless steel mast
• Remove the tubes of the stainless steel mast (F) from the pack-
aging.
• Join the tubes together.
• Put the previously mounted weather sensor to the narrow end of
the tube connector (G) (see fig. 3).
• Put the other end of the tube connector to the tube end of the
three-part stainless steel mast that is marked with a sticker (see
fig. 3).
