2. Layout and items supplied

Figures 1-57 can be found in the separate booklet
"Product illustrations for the Original Operating
Instructions"
2.1 Layout (Fig. 1-57)
1. Grass basket
2. Release lever for grass basket
3. Cutting height adjustor lever
4. Seat
5. Steering wheel
6. Accelerator pedal (reverse)
7. Accelerator pedal (forward)
8. Headlights
9. Front wheel
10. Mower unit
11. Rear wheel
12. Locking brake
13. Brake pedal
14. Throttle lever
15. Light switch
16. On/Off switch for the mower unit
17. Ignition lock
18. Ejector chute
19. Release lever for gears
20. Bar
21. 8-10mm open-ended wrench
22. 13-15 mm open-ended wrench
23. 10-12mm multi-functional wrench
24. 13-19 mm multi-functional wrench
25. 5 mm Allen key
26. Philips screwdriver
27. 2x ignition keys
28. Screw (cross recessed head)
29. Nut
30. Washer
31. Screw (internal hexagon)
32. Fuse (15 amps)
33. Petrol tank / fi lling cap
34. Viewing window for fuel level
35. Spark plug wrench
36. Trailer hitch
37. Battery
38. Blade, right
39. Blade, left
40. Handle
41. Oil fi lter
42. Oil fi lling cap
43. Oil drainage screw
44. Grass basket fi ll level sensor
45. Mower unit button
Anl_GE_TM_102_BS_SPK7.indb 22 Anl_GE_TM_102_BS_SPK7.indb 22
GB
2.2 Items supplied
Please check that the article is complete as spe-
cifi ed in the scope of delivery. If parts are missing,
please contact our service center or the nearest
branch of the DIY store where you made your
purchase at the latest within 5 work days after
purchasing the article and upon presentation of
a valid bill of purchase. Also, refer to the warranty
table in the warranty provisions at the end of the
operating instructions.
•
Open the packaging and take out the equip-
ment with care.
•
Remove the packaging material and any
packaging and/or transportation braces (if
present).
•
Check to see if all the items are supplied.
•
Inspect the equipment and accessories for
transport damage.
•
If possible, keep the packaging until the end
of the guarantee period.
Important.
The equipment and packaging material are
not toys. Do not let children play with plastic
bags, foils or small parts. There is a risk of
choking and suff ocating!
Important:
To prevent damage, set the mower unit to
the highest level when you unload the mo-
wer and push it slowly off the transportation
pallet.
Note: Place boards between the struts of the
transportation pallet.
You have to disengage the gears to be able to
push the mower. To do so, push the release
lever (Item 19) inwards and hook into place
(Fig. 13). Only do this with the engine swit-
ched off . For driving, the release lever has to
be moved to the outer position (Fig. 12). Only
do this with the engine switched off .
•
Lawn tractor
•
Seat
•
Steering wheel
•
Grass basket
•
Release lever for grass basket
•
Bar
•
2x ignition keys
•
Screw (cross recessed head)
•
Battery
•
Nut
•
Washer
•
Screw (internal hexagon)
