EN
2. Removing the LED spotlight:
A. First disconnect the cable leading to the LED
spotlight to be replaced. Disconnecting is done by
releasing the lock by applying a light pressure and
pulling it off at the same time.
B. Then remove the LED spotlight to be replaced by
making a soft rotating movement counterclockwise.
C. Remove the LED spotlight to be replaced from the
bayonet ring.
3. Mounting the new LED:
A. Place the new LED light into the locking ring.
B. Make a rotating movement to the right until the
LED light is locked.
C. Connect the power cable.

Colour LED lighting 2,700K (warm white) or
4,000K (neutral white) depending on choice
of connection. Make sure that all LED spots
are connected in the same way to prevent a
difference in colour of LED lighting.
D. Place the spotlight holder back in the cooker hood
and reconnect the power.
C
C old
W a rm
A
– 80 –
B
A
B
C
