Removing The Bottom Panel; Grease Filter - Novy Mini Pureline 810 Bedienungsanleitung

EN
Coated parts of the extractor hood
The extractor hood can be cleaned with a damp
cleansing tissue and a mild cleaning agent.
Glass
Glass parts of the extractor hood can be cleaned with
a soft cloth and a glass cleaner.
5.2

Removing the bottom panel

If the bottom panel is to be removed from the cooker
hood
for cleaning, proceed as follows:
− Grasp the bottom panel at the left and right ends.
− Slowly tilt the bottom panel downwards and continue
to hold it in place.
− As soon as the bottom panel is at a 90º angle
downwards, the bottom panel can be slid to the
right to remove it from the hinges. Here you will feel
some resistance. Do this with caution to prevent
damage to the cooker hood. Make sure you hold
the bottom panel securely at all times.
− The bottom panel can then be cleaned by hand.
The bottom panel is not suitable for cleaning in the
dishwasher.
− Before reinstalling the bottom panel, immediately
clean the accessible parts on the inside of the cooker
hood.
− To replace the bottom panel, grasp the bottom panel
at the left and right ends and hold it in place. Make
sure you hold the bottem panel securely at all times.
− Hold the bottom panel in a 90º angle downwards
and slide the bottom panel to the left over the hinges
until you notice a click.
− The bottom panel cannot be closed if the bottom
panel is not fully positioned over the hinges.
− The bottom panel can then be closed.
5.3

Grease filter

Indication cleaning grease filter

Indication: 4 flashing indicator lights
After 20 cooking hours 4 flashing indicator LEDs show
that the grease filter must be cleaned.
– 76 –
