Default settings shaded.
Menu
ADDR
XXCH
P-XX
SOUD
SLAV
DMX
DMX address setting
With this function, you can adjust the desired DMX-address via the Control Board.
• Select "d001" by pressing [Mode].
• Adjust the DMX address by pressing [UP] or [DN].
• Press [Mode] in order to return to main menu.
Adjust DMX channel mode
With this function, you can adjust the DMX channel mode.
• Select "5CH" by pressing [Mode].
• Press [UP] or [DN] to select "12CH" or "5CH.
• Press [Mode] in order to return to the main menu.
STAND-ALONE
Auto - internal programs
With the function "P-XX" you can run the 10 internal programs. You can set the program speed under
"S-XX" to a value between 1 and 99.
• Select "P-XX" by pressing [Mode].
• Adjust the desired internal program by pressing [UP] or [DN].
• Press [Mode] in order to return to main menu.
• Select "S-XX" by pressing [Mode].
• Press [UP] or [DN], in order to adjust a value between 1 and 99 (speed from 00 to 99, increasing).
• Press [Mode] in order to return to main menu.
Sound-control mode
The device features a built-in microphone, which provides automatic sound-control. You can adjust the
sensitivity with the rotary-control on the rearpanel.
• Select "SOUD" by pressing [Mode].
• Press [Mode] in order to return to the main menu.
SLAVE
Slave setting
With this function you can define the device as slave.
• Select "SLAV" by pressing [Mode].
Display
dXXX (1-512)
5CH
12CH
P-XX (1-10)
S-XX (1 slow -99 fast)
SOUD
SLAV
25/30
Function
DMX address setting
5 channel mode
12 channel mode
Auto - internal programs 1-10
- the device is defined as master
Speed for the internal programs
Sound-control mode
- the device is defined as master
The device is defined as slave
