Operation

Before use

WARNING! Before putting the device into
operation, you must check it for operational
safety. If you have any doubts, do not start
the device!
NOTICE! Remove the protective film from
the line cutter before using the device for the
first time (57).
Pay particular attention to the following
points:
• Check the cutting tools for damage and
wear.
• Correct assembly of the cutting head.
• Smooth operation of all switches.
• Secure fit of the spark plug connector. If
the plug is loose, sparks can occur and
ignite the escaping fuel/air mixture.
• Correct function of the clutch.
• Clean handles for safe handling of the
device.
• All safety and protective devices must be
properly installed and in place before the
device can be started.
The cutting head must be able to move
freely. Before starting the device, make sure
that the cutting head is correctly positioned
and that the moving parts are free.
WARNING! If you have any doubts, ask a
specialist at an authorised service centre to
help you operate this device.
Using the extension of the
protective cover
The extension of the protective cover must
be pulled in when using the 3-blade steel
cutter.
The extension of the protective cover must
be pulled out when using the spool.
Tools and aids required
• Slotted screwdriver
Pulling in the extension of the protective
cover (Fig. J)
1. Unlock the lock (58) on the extension of
the protective cover (27) using a slotted
screwdriver.
2. Push the extension of the protective cov-
er upwards as far as it will go. You will
hear the lock (58) on the extension of the
protective cover (27) click into place.
Extending the protective cover (Fig. J)
1. Press the lock (58) on the extension of
the protective cover (27) and push the
extension of the protective cover (27)
down as far as it will go.
2. Pull the extension of the protective cov-
er (27) downwards as far as it will go. You
will hear the lock (58) on the extension of
the protective cover (27) click into place.
NOTICE! Clean the extension and protective
cover of the tool after each use.
Adjusting the carrying harness
eyelet/balancing out the device
Select the correct position for the carrying
harness eyelet according to whether you are
using a spool or blade.
Requirements (Fig. K)
The scythe attached to the harness should
be used without touching it with your hand,
➊ The spool should rest lightly on the
ground.
➋ The blade should be balanced around 20
cm above the ground.
Procedure (Fig. K)
1. Loosen the wing screw (59) on the eye-
let (12) for the double shoulder strap.
Slightly tighten the wing screw again.
2. Depending on the cutting tool, balance
the scythe according to the above criter-
ia by moving the eyelet (12) on the upper
shaft tube (20).
3. Tighten the wing screw (59) when the
scythe is in the desired position.

Working with the spool

• In small grass areas hold the device at
an angle of about 30° and swing the cut-
ting head evenly to the right and left with
a semi-circular movement.
• The best results are obtained with a max-
imum grass length of 15 cm. If the grass
is taller, it is recommended to mow sever-
al times.
• To cut around trees, fence posts or other
obstacles, slowly move the device around
the obstacle and cut with the line ends.
• Avoid any contact with fixed obstacles
(e.g. rocks, walls, picket fences, etc.). The
line would wear out quickly. Use the edge
of the protective cover to keep the device
at the correct distance.
