PassWord Lock
With the UP/DOWN Buttons you can step to the next menu:
Menu 6
Re-Def- Press Enter to set back the unit to manufactureres settings.
With the UP/DOWN Buttons you can step to the next menu:
Menu 7
Reset Press Enter to reset the units functions
10.1.

Erase a password:

To set back the password to default do as described here:
MENU→UP/ DOWN→MENU SYS-SET→ENTER→UP/ DOWN→SYS-SET Password→ENTER→UP/
DOWN→NO→ENTER→password(default 988)→ENTER
11.

DMX Table

11.1.

DMX Table with 12 Channels

Ch Value
1 0 – 255
2 0 – 255
3 0 – 255
4 0 – 255
5 0 – 255
6 0 – 255
7 0 – 255
8 0 – 255
9 1 – 7
8 – 14
15 – 21
22 – 28
29 – 35
Function
Tilt
Tilt Fine
Dimmer 0 – 100%
Red Dimmer 0 – 100%
Green Dimer 0 – 100%
Blue Dimmer 0 – 100%
White Dimmer 0 – 100%
Strobe effects
Tilt Stand Alone Program 1
Tilt Stand Alone Program 2
Tilt Stand Alone Program 3
Tilt Stand Alone Program 4
Tilt Stand Alone Program 5
was turned off and has been turned on again.
The Default password is 988.
Proceed as with unlock but in this case choose
your own three numbers tos et a new password
to secure the unit from unwanted users.
Power off the fixture and turn it on again to
validate the changes.
18 / 23
