9.2. Button explanation

Function of the buttons:
MENU
UP
Down
ENTER

9.3. Wiring

DMX IN
DMX OUT
POWER IN
Changes the function main menu
Steps up through the different pages
Or increases the value if you set up numbers.
Steps down through the different pages
Or decreases the value if you set up numbers.
Confirms your changes.
Here you can plug your dmx signal cable coming
from your console or master slave mode from
your master unit
From here you can connect and daisy chain the
next unit, make sure you are working according
the DMX512 restrictions!
Here you can plug the included power plug cable.
Make sure first to plug the cable into the item and
then into the mains!
