Switching
Switching via keys F21 and F22
IMPORTANT:
Switching between the channels via
default settings of the KVM switch.
An alternative to switching channels with select keys is to use the
on your keyboard.
After enabling the switching of channels (see page 24), press
1 or
to switch to channel 2 of the KVM switch.
F22
Switching via step keys
IMPORTANT:
Step keys are deactivated in the default settings. Information on how
to enable this function are provided on page 24.
Alternative to using select keys to switch between channels connected to the KVM
switch is to use the step keys to switch the channels in ascending or descending order.
IMPORTANT:
The active step keys depend on the selected select keys. The following
table lists the step keys depending on the active select keys.
Select keys
1 ... 2
NUM 1 ... 2
A ... B
F1 ... F2
How to use step keys to switch to a certain channel:
1. Press
Hotkey+»Back« step key
console keyboard.
Switching via serial device
The channels can be switched via a serial device connected to the Service port of the
KVM switch. The serial device can either be a special keypad or a computer which
is terminal emulator operated.
IMPORTANT:
Use the following connection settings and the switching commands of
the KVM switch to successfully switch the channel with a serial end device.
10 · G&D DVIMUX2-DL-USB
»Back« step key
9
NUM 9
I
F9
or
Hotkey+»Forward« step key
and
is deactivated in the
F21
F22
F21
to switch to channel
F21
»Forward« step key
0
NUM 0
K
F10
on the
and
keys
F22
