7. Create System Successfully: System creation successful. You can rename your system and then use it.
• Create with SolarFlow 2400 AC+'s initialization.
After successfully adding the SolarFlow 2400 AC+, you can complete the system creation through the device
initialization guide.

10.5.2 System Status

1. Solar Panel
Display the power input from the solar panels within the system, and view the branch data.
2. Appliances
Display the type of electricity consumption data currently being used to control the output of the energy storage system.
As shown in the figure, the current system has not configured any sensors (Smart Appliances), the energy system
automatically outputs according to the basic load plan. If the system is connected to a Smart Appliance, this will
display the monitored values of the devices.
3. Device status
Display the energy storage devices within the current energy system, as well as their charging and discharging status.
Click to view the detailed status of energy storage devices.
As shown in the figure, when the battery is fully discharged or fully charged, the battery will enter bypass mode, and
the input energy from the solar panels will be directly output to the home.
If you want to allow the system to continue charging or discharging, you only need to go to the system settings and
adjust the limit of battery charging and discharging according to your own usage needs.
4. Total Output / Input
The total discharge or charging power of all energy storage devices to the home.
If the maximum safe value is reached, a "Max" mark will be displayed (as shown in the figure below). Clicking the
"Max" mark can adjust the safe value.
5. Grid
If a Smart Meter is installed in the system, the energy flow between the home and the grid can be detected here.
6. Outlet Load
If your device supports an off-grid outlet, the system will summarize the data of all devices with off-grid outlets here.
Max
