Kemper KTS ComLog module Bedienungsanleitung Seite 14

EN
1
Technical information
1.1
Layout

Components

Housing cover

Housing base

Power pack 230V AC / 24V DC

ComLog with SD card sloth with SD memory card (1 GB)

Modus interface
1.2
Scope of delivery
1.3
Technical Data | Dimensions
Specifications
Max. ambient temperature
Width
Height
Depth
Weight
Material
Protection class
14 / 24 – K410095502001-00 / 03.2020 – © www.kemper-olpe.de
Housing (IP65)
ComLog module
SD card (1GB)
Power pack (230V AV / 24V DC)
[mm]
[mm]
[mm]
Figure 1 - Structure ComLog module
Unit ComLog module housing
[°C]
[kg]




40
120
222
162
1
ABS
IP 65
