The operator has to make sure that safety-relating and machine-technical installations are inspected by a
skilled person once a year.
The following points have to be considered during the inspection:
1) All screws used for installing the devices or parts of the device have to be tighly connected and must not
be corroded.
2) There must not be any deformations on housings, fixations and installation spots (ceiling, suspension,
trussing).
3) The electric power supply cables must not show any damages, material fatigue (e.g. porous cables) or
sediments. Further instructions depending on the installation spot and usage have to be adhered by a
skilled installer and any safety problems have to be removed.
We recommend a frequent cleaning of the device. Please use a moist, lint-free cloth. Never use alcohol or
solvents!
There are no serviceable parts inside the device except for the lamp. Maintenance and service operations
are only to be carried out by authorized dealers.
Please refer to the instructions under "Installing/Replacing the lamps".
Should you need any spare parts, please use genuine parts.
Should you have further questions, please contact your dealer.
TECHNICAL SPECIFICATIONS
Power supply:
Power consumption:
Dimensions RDL (DxW):
Mounting dimensions (Diameter):
Dimensions SDL (LxWxH):
Mounting dimensions (LxW):
Weight:
Maximum ambient temperature T
Maximum housing temperature T
Fitting lamps:
OMNILUX HQI-TS 70W R7s 117mm pole-burner
OMNILUX 230V/100W R7s 117mm pole-burner
Recommended ballast resistor:
Ballast resistor for 70W Downlight
DANGER TO LIFE!
Disconnect from mains before starting maintenance operation!
RDL-70/SDL-70:
:
a
(steady state):
B
(no ballast resistor necessary)
16/17
50808200, 50808250,
50808252, 50808254
230 V AC, 50 Hz ~
circa 105 W
223 x 130 mm
220 mm
230 x 130 x 140 mm
218 x 128 mm
1 kg
45° C
200° C
Best.-Nr.
91013105
91100075
No.:
50808500
