PRODUCT DESCRIPTION

Electrically-assisted bike technical features

F
A
Battery 36 V / 10.5 Ah
B
Battery lock handle and barrel
C
Controller
D
LED control screen
E
Cable from the control screen to the controller

General operation of the electrical assistance

The electrically assisted bicycle can be used with or without assistance by pressing the ON/OFF button and playing around with the 0 - ECO -
NORMAL - BOOST modes. The 0 - ECO - NORMAL - BOOST assistance modes, which you can select in the «D» screen, let you choose a level
of electrical assistance in addition to the effort provided. Power assistance will only work if you are pedalling, with a mode selected other than 0.
Assistance cuts off when the speed is above 25km/h. In case of intensive use and in exceptional climatic conditions, assistance may be cut off to
safeguard the whole system.
The power supplied is calculated by the «C» controller according to your pedalling rate. Depending on the mode selected, the «C» controller sends
more or less current to the «F» motor to provide you with the assistance you require

Power assistance does not activate or shuts down in the following situations:

- The speed is above 25km/h
- You're not pedalling
- The remaining charge in the battery is not sufficient
- «0» is the power assistance mode selected
- When the control screen is switched off
- In case of intensive use and in exceptional climatic conditions, assistance may be cut off to safeguard the whole system
I
C
G
A
B
F
Motor 250 Watt / 42 Nm
G
Pedalling detector
H
Front lamp 6-12V LED
I
Rear lamp 12V
6
D
E
H
