RT150CW4/ RT135CW4 PARTS LIST:
ITEM Name PICTURE Q'TY ITEM Name PICTURE Q'TY
Air
1 conditioning 1PCS 2 manual 1PCS
unit
INSTALLATION INSTRUCTIONS
1. Choosing Proper Location for Unit.
This unit is specifically designed for installation on the roof of an Marine rooftop Air
conditioner. When determining your cooling requirements, the following should be
considered:
 Size of Marine rooftop Air conditioner;
 Window area (increases heat gain);
 Amount of insulation in walls and roof;
 Geographical location where the Marine rooftop Air conditioner will be used;
 Personal comfort level required.
Normal locations-The unit is designed to fit over an existing roof vent opening.
Other locations-When no roof vent is available or another location is desired, the
following is recommended:
1.1. For one unit installation: The unit should be mounted slightly forward of center
(front to back) and centered from side to side.
1.2. For two-unit installations: Install one-unit 1/3- and one-unit 2/3's from front of
Marine rooftop Air conditioner and centered from side to side. It is preferred that
the unit be installed on a relatively flat and level roof section measured with the
Marine rooftop Air conditioner parked on a level surface.
The maximum inclination Angle is 8°.
