6.4 ADVANCED CONFIG
6.4.1 CAMERA
CAMERA
CH1 CH2 CH3 CH4
DETECTION
ALERT
NETWORK
DISPLAY
RECORD
DEVICES
DCCS
IVS
NOTIFY
EXIT
1)
BRIGHTNESS / CONTRAST / SATURATION / HUE
Click the current value to manually adjust the brightness/contrast/saturation/hue of each channel here.
2)
REC
Select if you want to enable recording for the selected channel (ON / OFF).
Note: When this function is disabled, no manual, event or timer recording will be activated even if any
of these three record functions is set to "ON".
3)
TIME STAMP DISPLAY
Enable this function and the recording time will be shown on the video during video playback.
4)
CHANNEL TITLE
Click the channel title column to change the channel title (up to 12 characters). The default title is the
channel number.
5)
REC AUDIO
Enable or disable audio recording for the selected channel if the connected camera supports audio
recording.
6)
ALARM OUT DURATION (SECS)
Select the duration time in second when an alarm-out event occurs (3 / 5 / 10 / 20 / 30).
7)
CAMERA PARAMETERS UPGRADE
This function is used only to upgrade our brand's HD CCTV camera.
Get the upgrade file from our installer or distributor and save it to a USB flash drive. Then, select
"UPGRADE" to start upgrade the camera parameters.
ADVANCED CONFIG
INTERFACE
BRIGHTNESS
CONTRAST
SATURATION
HUE
REC
TIME STAMP DISPLAY
CHANNEL TITLE
REC AUDIO
ALARM OUT DURATION (SECS)
CAMERA PARAMETERS UPGRADE
(For selected models only)
(For selected models only)
32
COAXIAL
128
128
128
128
ON
ON
CH1
ON
3
UPGRADE
MAIN MENU
