PROOF S6 -

Dimensions

All dimensions in mm
S6 flush-mount set:
12 V=
B L
PWH R
1/2" IT
Power supply: 2 x 0.5–1.5 mm
Attention: Do not install the power supply in the flush-mount set or protected zones, if applicable.
Cabling for WimTec bus system: 2 x 0.2–1.5 mm
HyPlus
185
Outlet of head shower
R 1/2" IT
140
152
total cable length max. 100 m.
2
Shower control
20
11
Brickwork
Tile
23
Plaster
PWC R
1/2" IT
Sealing
collar
26
min 95 max 120
2 YSLCY-OZ, max. 100 m total cable length.
WimTec PROOF S6 -
EN
27
HyPlus
