EN
CROSS LINE LASER
SAFETY REGULATIONS
The user manual should be read carefully before you use the product for the first time.
Unintended use of the product can be dangerous for human's health and cause serious injury.
Keep this user manual. If the product is given to somebody for temporary use, be sure to
enclose user manual to it.
- Do not misuse the product
- Do not remove warning signs and protect them from abrasion, because they contain
- Do not look into the laser beam or its reflection, with unprotected eye or through an optical
instrument. Do not point the laser beam at people or animals without the need. You can dazzle
them.
- To protect your eyes close them or look aside.
- It is prohibited to disassemble or repair the product yourself. Intrust product repair to
qualified personnel and use original spare parts only.
- Do not use the product in explosive environment, close to flammable materials.
- Avoid heating the batteries to avoid the risk of explosion and electrolyte leakage. In case of
liquid contact with skin, wash it immediately with soap and water. In case of contact with eyes,
flush with clean water during 10 minutes and consult the doctor.
10
CONDTROL UniX 360 Pro
User manual
information about safe operation of the product.
The device belongs to laser product class 2 in
accordance with
EN 60825-1 with a 630-670 nm wavelength.
EN
CROSS LINE LASER
OPERATION
Remove the battery cover. Insert the batteries, observing correct polarity.
Put the battery cover back. Place an instrument on a tripod or on a firm and stable surface.
To switch on an instrument, move compensator (8) to the right position to release. By
consecutive pressing of the Mode switching button (2) the instrument is switched to the
different operating modes. To use Electronic Receiver press button (3) switch on/off pulse
mode.
The following 2 operating modes are available:
- Operation with the automatic compensation to project horizontal and vertical laser lines
and planes. The compensator automatically aligns instrument's position within the range
of compensation ±5°. The laser beam starts to blink along with a sound alarm when the
instrument is out of the range of the automatic compensation.
- Without Automatic Levelling mode to construct inclined planes.
To switch on/off automatic levelling press and hold (no less than 2 sec.) button (3). At the
switched off automatic compensation you can freely hold the instrument in your hand or place
it on a suitable surface. Laser beams will work stable without blinking, no sound alarm to signal.
To switch off the instrument and/or prepare it for transportation move compensator (8) to the
left position, the levelling unit is blocked. When the battery indicator (4) and laser planes are
blinking, the batteries must be replaced.
CONDTROL UniX 360 Pro
User manual
11
