Commissioning; Setting The Release Angle (Optional) - Becker Centronic SensorControl SC211-II Montage & Betriebsanleitung

Caution
It is essential to follow the steps in the correct order.
1. Open the housing and carefully remove the PCB
2. Insert batteries correctly.

3. Setting the release angle (optional)

Caution
The release angle may only be set by a specialist in accord-
ance with the specific features of the articulated-arm awn-
ing.
1. Set the release angle on the rotary switch.
Rotary switch for the release angle
2. This completes the setting process.
The factory default is 0 (off).
The release angle setting is applied once the initial angle of
inclination is set.
22 - en

Commissioning
