5. Disconnect the three connectors as shown shaded in the figure below.
6. Remove 1off pozi head screw (M4x10), with flat and spring washer, and
remove the CD Drive in the direction of the arrow, as shown below, taking
care not to bend the hook on the rear of the Drive.
CD-ROM drive
Hook
7. Remove 4off pozi head screws (M3x6), with flat and spring washers, from
the bottom of the CD Drive.
CD-ROM
bracket
CD-ROM drive
8. Reassemble in reverse order.
Note: When shipping the CD Drive, ensure that it is wrapped in sponge
or bubble-wrap and packed in a strong carton to prevent damage.
Pozi head screw(M3x6)
(with flat/spring washer
Page 60
Connectors
Pozi head screw (M4x10)
(with flat/spring washer)
