RF Rx SW868/915/917/922-NET-4S-A
Montage- und Anschlussanleitung / Funk-Aktor
Mounting and wiring instructions / Wireless actor
English
Transmission power SW868, SW915, SW917: <25 mW
SW922: <1 mW
Data rate 66 kbps
Channel bandwidth SW868: 480 kHz, SW915, SW917: 550 kHz,
SW922: 520 kHz
Wireless range SW868, SW915, SW917:
max. 700 m outdoors,
max. 50 m indoors
SW922:
max. 230 m outdoors,
max. 25 m indoors
Display green LED: ready for operation,
orange LED: signalling of switching state
Operation cycles max. 12,000 telegrams at repetitions/h;
SW922: max. 1,440 telegrams/h
Degree of pollution 2
Ambient temperature 0°C ... +55°C
Storage and shipping
temperature -25°C ... +85°C
External antenna always required for optimum wireless range
Note Inductive loads (contactors, relays etc.) are to
be suppressed by suitable circuitry. Switching
contacts are not suitable for capacitive loads.
Wireless approvals EU: RED 2014/53/EU
USA: FCC - XK5-RFRXSW915
Canada: IC - 5158A-RFRXSW915
Mexico: IFT - RCPSTRF17-1886
Brazil:
Japan:
Herstellungsdatum 013526
Production date
01 Montag Monday
02 Dienstag Tuesday
03 Mittwoch Wednesday
04 Donnerstag Thursday
05 Freitag Friday
04172-18-06718
ö
ARIB STD-T108: 204-610002
?
➡
Montag KW 35 / 2026
Monday CW 35 / 2026
