N) Function "14:Th Hold", Throttle Hold - ModelCraft MC30 Kurzanleitung

n) Function "14:TH HOLD", Throttle Hold

This allows a position for the gas/brake servo to be programmed, this position
is applied after the "TH.HOLD" button (see fig 1, pos 8).
Then the gas/brake operating lever has no effect (see fig 1, pos 5) until the
"TH.HOLD" button is pressed once again.
This function can not only be used as a choke when the motor is started but
also as protection against unwanted operation of the operating lever or as a
type of "emergency-stop" with full brake application.
Proceed as follows:
• From within the main menu (see fig. 5) press the "ENTER" button, then you
can use the "+" or "-" buttons to select the "14:TH HOLD" function (fig 78).
• Then press the "ENTER" button again to reach the settings menu (fig 79).
• The servo position can be set with the "+" and "-" buttons (setting range
-120% to +120%).
• Exit the settings menu with the "EXIT" button, the settings are automatically
saved.
Function11.2V
13:MIX
14:TH HOLD
15:F/S
16:NEUTRAL
TH.HOLD 11.2V
TH.HOLD:
VALUE: 15%
Figure 78
Figure 79
87
