Retain all warnings and instructions for future use.
The SAS+ALL series is designed to work
exclusively with SAS+ALL series chargers and
batteries. We recommend using 4 Ah or 5 Ah batteries for
lawnmowers.
The battery and charger are not included in the equipment purchased
and must be purchased separately. It is prohibited to use batteries and
chargers other than those intended for this equipment.
2. Description of the device
Pic. A: 1 - handle, 2 - on/off rod, 3 - switch, 4 - handle clamps, 5 - waste
container, 6 - battery and safety key sockets, 7 - cutting height adjustment
lever
3. Purpose of the device
The cordless mower is designed for mowing grass on flat and level
surfaces, as well as on slopes with a slight incline. The mower allows to
collect the grass into a container or to work without one. The use of
batteries makes it possible to mow lawns in places where there is no
access to mains power.
It is permissible to use the device in renovation and construction work,
repair workshops, amateur work, subject to the conditions of use and
permissible working conditions contained in the operating instructions.
4. Restriction on use
The appliance may only be used in accordance
with the 'Permitted operating conditions' below.
The mower must not be used for trimming overgrowth, clipping stems,
rhodraping cut stems, clearing paths, levelling uneven areas (e.g.
mounds made by moles) and other activities.
Unauthorised changes to the mechanical and
electrical design, any modifications, maintenance
operations not described in the operating instructions will be
treated as illegal and will result in the immediate loss of warranty
rights and the declaration of conformity will become invalid.
Misuse or use not in accordance with the operating instructions will result
in immediate loss of warranty rights.
Permitted operating conditions'
S1 - continuous operation and others.
Battery charging temperature range 10 - 30°C. Do not expose to
temperatures above 40°C.

5. Technical data

Model type
Rated voltage [V]
IP number
Max. speed n0 [min-1]
Tank capacity [L]
Working width [mm]
Cutting height [mm - mm]
Handle vibration level [m/s2]:
Uncertainty ka [m/s2]
Sound pressure level LpA [dB(A)]
Uncertainty kpA [dB(A)]
Sound power level LwA [dB(A)]
Uncertainty kwA [dB(A)]
Guaranteed sound power level LWA [dB(A)]
Weight [kg]
Information on vibrations and noise
The combined value of the vibration ah and the measurement uncertainty
were determined in accordance with the standard EN 62841-14 and are
given in the table.
Noise emissions were determined in accordance with the standard EN
62841-14, and values are given in the table above.
Noise can cause hearing damage, always wear
hearing protection when working!
The declared total vibration/noise value has been measured according to
a standard test method and can be used to compare one device with
another. The stated vibration/noise level can also be used for a
preliminary vibration/noise exposure assessment.
Vibration/noise levels during actual use of the equipment may differ from
the declared values, depending on the use of the work tools, in particular
the type of workpiece and the need to determine operator protection
measures. To accurately estimate exposure in actual use conditions, all
parts of the work cycle must be considered, including periods when the
machine is switched off or when it is switched on but not used for work.
6. Preparing for use
charger must be completed. The use of other batteries and chargers
is prohibited.
Assembling the handle.
Unfold the handle, place it in position and lock it in place using the lever
screws.
Attaching the grass catcher
When mowing with the grass catcher, raise the ejection duct cover,
remove the ejection duct cap, place the catcher hooks in the handles and
then lower the cover.
Installing the batteries
The battery sockets are located on the body of the mower, under the
transparent plastic cover. To fit the batteries, lift the cover and slide the
batteries into the sockets.
Two batteries should be placed side by side. Even when four
batteries are fitted, the motor will draw current from a set of two
batteries, and when they are discharged, it will switch to another
two batteries (provided they are slotted in).
Use batteries with the same characteristics.
7. Switching on the device
„Przygotowanie do pracy".
Slide the charged batteries into the guide in the battery slot until the
handle latch engages. We then place the key in the ignition, making sure
that the notch of the key fits into the groove in the ignition. The unit is now
ready for use.
The mower is started using a sequence - first press the button, located in
the switch. While holding the button down, pull the stick slightly towards
the handle of the mower. The engine will start. When you let go of the
button on the switch the engine will continue to run, letting go of the
handle will switch off the engine.
8. Operation of the device
must be strictly observed..
DED6997X
Regular mowing of the grass is a maintenance procedure, it stimulates
DED6997X-2A5
the grass to grow, increases its density and causes weeds to die. The
36 (18 x 2)
first mowing should be carried out at the beginning of April, when the
IPX1
grass is 70-80 mm high. During the season, the grass should be mowed
2800-3200
once a week.
65
Do not start the mower in tall grass.
460
Before you start mowing, select the cutting height. To do this, use the
30-75
lever to select the cutting height so that the lever is in the desired position.
2,5
Select the cutting height so as not to overload the mower.
1,5
Mowing must be carried out in straight strips and in an overlapping
77,4
pattern, i.e. each successive pass should overlap approx. ¼ of the
3,0
previous pass. When mowing on a slope, mow across the slope and be
88,2
particularly careful when reversing and changing the direction of mowing.
1,88
The grass catcher is equipped with a fill level indicator. When mowing,
96 ensure the grass catcher is full. Empty the grass catcher regularly and do
not allow it to overfill.
19,6
Mowing without a catcher
The mower allows you to mow without a basket. During this operation,
the grass is scattered over the lawn. The cut grass decomposes, turning
into a natural, organic fertiliser. This improves grass growth by reducing
water evaporation, preventing soil erosion, slowing weed growth, etc.
Once the basket has been removed, a cap should be fitted to the ejection
channel. The grass cuttings will be spread under the mower housing.
Disconnecting the power supply
Disconnect the power source each time:
- if you walk away from the machine
- before clearing an obstruction
- before checking, cleaning or operating the machine
- after hitting a foreign object to visually check that the machine is not
damaged
- if the machine starts to vibrate excessively, for an immediate check.
The device is part of the SAS+ALL line, so to use
it, a kit consisting of the device, battery and
All operations described in this chapter should be
carried out with the battery disconnected.
Przed uruchomieniem urządzenia bezwzględnie
wykonać czynności opisane
If the battery gets hotter than 40°C, stop operation
and wait for the battery to cool down.
When operating the device, all safety rules and
instructions described in the safety conditions
w rozdziale
