Specifications - Varde IN-line 47 Einbauanleitung

Specifications

varde in-line47
| Nominal heat output: 6 kW (4­8 kW)
| Heats up to: 30­90 m
| Weight: 92 kg
| Smoke outlet: Ø 15 cm
| Exterior dimensions: height 46,5 x width 68 x depth 42 cm
| Exterior dimensions of front frame: height 58,5 x width 77 cm
varde in-line 55
varde front-line 55
| Nominal heat output: 7 kW (4­9 kW)
| Heats up to: 30­100 m
| Weight: 102 kg
| Smoke outlet: Ø 15 cm
| Exterior dimensions: height 54.5 x width 68 x depth 42 cm
| Exterior dimensions of front frame: height 66.5 x width 77 cm
D
* it is possible to buy a special front­frame to In­Line 55 and Front­Line 55 wich reduces the
needed depth to 40 cm
20
2
2
H
W
aperture dimensions for
standard frames:
Height: See the sketches under
"Building in"
Width: 70­75 cm
Depth: Min. 46 cm*
.
