3 Flexible tubing
To connect the fireplace insert to the chimney, you must first install the
flexible tubing in the chimney.
| Pull the tubing 20­30 cm up into the chimney from the fireplace, until
the access hatch is reached.
| Note the flow arrow indicating the direction of the smoke through the tubing.
| Apply insulation batts to insulate the tubing. Leave the top 2­3 cm
uncovered to facilitate the subsequent walling­in of the tubing (see point 8).
4 Flue
Once the tubing is secured in the chimney, the accompanying 45˚ flue
should be attached to the other end of the tubing.
| Fit the flue to the tubing, and fasten with a jubilee clip or the like.
