Varde IN-line 47 Einbauanleitung Seite 19

7 Adjustment
Before replacing the vermiculite plates and the base slab, adjust the fire­
place insert until it is straight and flush with the front of the fireplace.
| Adjust the four screws in the bottom of the insert, as shown.
| A spirit level may be used to ensure that the insert is level.
| You can also fasten the insert to the bottom of the fireplace with a
couple of frame screws, concrete screws or the like, via the two large
holes in the base.
8 Completion
The fireplace insert must be reassembled before it is ready for use.
| Replace the vermiculite plates and the base slab in the insert, in the
order shown.
| Fill in the top 2­3 cm with fireplace mortar to fix the tubing in place.
Your fireplace insert is now ready for use.
See the sections on Lighting and Stoking.
2
1
3
ENglIsh
19
