• Ensure that the cutout on the screen locates to the tab on
the attachment body.I
• Fit the mincer screen securing collar. Take care when fitting
the collar to prevent damage to the product.
• Hold down the attachment retainer pin whilst fitting the
attachments J.
• Align the flats of the shaft end to approximately the same
angle as that of the drive and insert into the drive J.
• Rotate the attachment slightly until it locates to the drive
and push into place.
• Release the attachment retainer pin and rotate the
attachment slightly until the hole on the attachment locates
to the retainer pin on the main unit drive hub K.
• Tighten the securing collar as much as possible. The best
way to do this is to hold the feed tube with one hand and
the spanner in the other hand and turn clockwise L.
NOTE: it may be necessary to tighten this collar again during
use.
• Fit the food tray into the food throat and locate the tray
underneath the outlet to catch processed food M.
Operating Instructions
• The fine mincer screen is for raw and cooked meat, fish
and small nuts.
• The coarse mincer screen is for raw meat, fish, nuts,
vegetables, hard cheese, fruit peel and dried fruit.
• Fit the appropriate screen as described above in assembly
instructions.
• Cut the meat and vegetables into cubes of 25mm
maximum.
• Feed the cubed food into the feed tube.
• Use the pusher to move the food down the tube, no
pressure is required at all.
• Operate the machine on Speed 4.
VEGATABLE SHREDDER ATTACHMENT
• Always unplug the product before putting on or taking off
attachments
• Remove the attachment hub cover at the front of the
product N.
Features
ı Food pusher
ˆ Main housing and feed tube
˜ Drive shaft
¯ Fine grating / shredding cone
˘ Cone retaining collar
% Coarse grating / shredding cone
& Fine slicing cone
( Coarse slicing cone
8
18/3/10 09:16 Page 8
Assembly instructions
• Choose the appropriate cone for the application.
• Affix the shaft to the cone by aligning the fixing tabs on the
shaft to the holes in the base of the cone O.
• Twist the shaft clockwise to lock into place.
• Locate the shaft end into the main housing hub.
• Screw the cone retaining collar into place. Take care when
fitting the collar to prevent damage to the product.
• Hold down the attachment retainer pin whilst fitting the
attachments.
• Align the flats of the shaft end to approximately the same
angle as that of the drive and insert into the drive P.
• Rotate the attachment slightly until it locates to the drive
and push into place Q.
• Release the attachment retainer pin and rotate the
attachment slightly until the hole on the attachment locates
to the retainer pin on the main unit drive hub R.
Operating Instructions
• The fine shredder is for finely shredding and the coarse
shredder is for coarsely shredding hard or crisp vegetables
(e.g. carrots, turnips, potatoes, but also hard cheese, nuts
and dry bread).
• The thick slicer is for slicing firm foods. It is particularly
suitable for preparing vegetables to be steamed, fried,
creamed or scalloped.
• The thin slicer is suitable for shredding vegetables for
coleslaw, potato crisps, bread, celery, cucumbers, nuts and
pickles.
• Fit the appropriate shredding or slicing cones as described
above in assembly instructions.
• Cut the vegetables into cubes of 25mm maximum.
• Feed the cubed vegetables into the feed tube.
• Use the pusher to move the food down the tube, no
pressure is required at all.
• Operate the machine on Speed 4.
Cleaning
Before cleaning and maintenance, switch the appliance off
and unplug from the mains.
1 Remove all attachments. All attachments can be washed in
warm soapy water. Ensure that they are thoroughly dried.
2 Wipe the outside of the mixer with a damp cloth, then leave
to air dry. Never use abrasives or immerse in water.
3 Wash the bowl in hot soapy water. After cleaning re-fit the
bowl. This will keep the mixer head mechanism covered.
4 Fill the blender with warm water, fit the lid and goblet, then
switch on to MAX for 20-30 seconds. Empty then rinse.
Wipe then leave to air dry.
• Do not leave the blender in water to soak or leave water in
the blender.
(Certain models only).
(Certain models only).
