Nederman Pneumatic Track System Bedienungsanleitung Seite 6

Pneumatic Track System, Track length 5.9 m or 9.4 m
2
3
A
1300 N
(292 lbs)
0.5 - 0.6 m
(1 ft 8 in – 2 ft)
C
6
1
1300 N (292 lbs)
~ 2.4 m (8 ft)
1300 N (292 lbs) 1300 N (292 lbs)
D
2
B
1300 N
(292 lbs)
