EN Pneumatic Track System, Track length 5.9 m or 9.4 m
4.2
Mounting height
Track length
Material, track
Compressed air connection
Compressed air in the system
5
5.1
NOTE! The vehicle's parking position must be on the opposite side of the track
compared to the duct connection. See figure 1, alternatives 1 and 2.
5.2
14

Technical data

Table 4-1: Technical data PTS

Installation

Before installation

See figure 1. Before the PTS system can be installed, a suitable position must
be determined in relation to the vehicle's parking position in the station.
The distance from the floor to the bottom edge of the track should normally
be 3 - 4 m (10 - 13 ft). 3.5 m (11 ft 6 in) is recommended. If the system is to
be used between two vehicles, the distance between the vehicles must be at
least 1.2 m (4 ft).
The distance from the track's front edge to the station door threshold should
be at least 1.0 m (3 ft), see figure 1(A). Make sure the door can open freely
without interference to the track. See A.

Installation instructions

See figures 2, 3 and 4, items 1 to 14.
1. Place all the track profiles in line with each other on the floor. Screw the
profiles together with the lengthening joints. See figure 2(1).
2. Fasten the mounting brackets in the middle of every other profile. See
figure 2(2) and 2(3).
3. Lift the tracks and fit them in the ceiling.
NOTE! Check that there is no gap between the track sections.
The mounting devices should be fixed in bars, brackets or similar
arrangements according to the examples. The first and the last mounting
bracket should be braced. See figure 2(3), items A and B. All mounting
brackets should be braced with bracing bars positioned sideways
according to one of the items C and D figure 2(3). When mounting the
track, ensure that suitable fixing bolts are used considering the ceiling
3-4 m (10-13 ft)
3,5 m (11 pi 6 in) recommended
5.9 m (19 ft 4 in) or
9.4 m (30 ft 10 in)
Aluminium
6-8 bar (87-116 psi)
1 bar (14.5 psi)
